R&S FSPN - Remote Commands to Configure Level Characteristics

Remote Control
R&S
®
FSPN
350User Manual 1179.4363.02 ─ 01
Parameters:
<Value> bit values in hexadecimal format
TTL type voltage levels (max. 5V)
Range: #B00000000 to #B00111111
Example:
OUTP:UPOR #B00100100
Sets pins 5 and 7 to 5 V.
11.6.4 Remote Commands to Configure Level Characteristics
Functions to configure level characteristics described elsewhere:
●
INPut<ip>:COUPling
●
[SENSe:]POWer:RLEVel:MODE
DISPlay[:WINDow<n>]:TRACe<t>:X[:SCALe]................................................................... 350
DISPlay[:WINDow<n>]:TRACe<t>:X[:SCALe]:AUTO......................................................... 351
DISPlay[:WINDow<n>]:TRACe<t>:X:SPACing?.................................................................351
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]................................................................... 351
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:AUTO......................................................... 352
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel........................................................352
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:LOWer............................................ 353
DISPlay[:WINDow<n>]:TRACe<t>:Y:UNIT........................................................................353
INPut<1|2>:ATTenuation................................................................................................. 354
INPut<1|2>:ATTenuation:AUTO....................................................................................... 354
[SENSe:]ADJust:CONFigure:LEVel:THReshold.................................................................355
[SENSe:]POWer:RLEVel?...............................................................................................355
[SENSe:]POWer:RLEVel:OFFSet.................................................................................... 355
DISPlay[:WINDow<n>]:TRACe<t>:X[:SCALe] <Range>
This command defines the display range of the x-axis.
Prerequisites for this command
●
Turn off automatic scaling of the x-axis (DISPlay[:WINDow<n>]:TRACe<t>:
X[:SCALe]:AUTO).
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Range> Default unit: Depending on the selected diagram
Example: //Define a value range of 100 MHz.
DISP:TRAC:X:AUTO OFF
DISP:TRAC:X 100 MHz
Common Measurement Settings
