Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Level> <numeric value>
Default unit: Depending on the selected diagram
Example: //Define maximum level on the y-axis
DISP:TRAC:Y:RLEV -20
Manual operation: See "Scaling the y-axis" on page 104
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:LOWer <Level>
This command defines the minimum level displayed on the y-axis.
Prerequisites for this command
●
Turn off automatic scaling of the y-axis (DISPlay[:WINDow<n>]:TRACe<t>:
Y[:SCALe]:AUTO).
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Level> <numeric value>
Default unit: Depending on the selected diagram
Example: //Query minimum level on the y-axis
DISP:TRAC:Y:RLEV:LOW?
would return, e.g.
-135
Manual operation: See "Scaling the y-axis" on page 104
DISPlay[:WINDow<n>]:TRACe<t>:Y:UNIT <Unit>
This command selects the unit of the y-axis.
Available for baseband noise measurements.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
