Remote Control
R&S
®
FSPN
352User Manual 1179.4363.02 ─ 01
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Range> <numeric value>
Default unit: Depending on the selected diagram
Example: //Define a value range of 100 dB.
DISP:TRAC:Y:AUTO OFF
DISP:TRAC:Y 100
Manual operation: See "Scaling the y-axis" on page 104
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:AUTO <Mode>
This command turns automatic scaling of the y-axis in graphical result displays on and
off.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Mode> ON | 1
Scales the y-axis after each measurement.
OFF | 0
Allows you to define the scale manually.
ONCE
Scales the y-axis once. The scale remains the same for subse-
quent measurements.
*RST: ON
Example: //Select manual scaling of the y-axis.
DISP:TRAC:Y:AUTO OFF
Manual operation: See "Scaling the y-axis" on page 104
See "Scaling the y-axis of the phase diagram" on page 138
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel <Level>
This command defines the maximum level displayed on the y-axis.
Prerequisites for this command
●
Turn off automatic scaling of the y-axis (DISPlay[:WINDow<n>]:TRACe<t>:
Y[:SCALe]:AUTO).
Common Measurement Settings
