DISPlay[:WINDow<n>]:TRACe<t>:X[:SCALe]:AUTO <Mode>
This command turns automatic configuration of the horizontal axis on and off.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Mode> ON | 1
Scales the x-axis after each measurement.
OFF | 0
Allows you to define the scale manually.
ONCE
Scales the x-axis once. The scale remains the same for subse-
quent measurements.
*RST: ON
Example: //Select manual scaling of the x-axis.
DISP:TRAC:X:AUTO OFF
DISPlay[:WINDow<n>]:TRACe<t>:X:SPACing?
This command queries the scale of the x-axis in any measurement window.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Return values:
<Spacing> LINear
X-axis has a linear scale.
LOGarithmic
X-axis has a logarithmic scale.
Example: //Query scale of the x-axis in the second measurement window
DISP:WIND2:TRAC:X:SPAC?
Usage: Query only
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe] <Range>
This command defines the value range displayed on the y-axis.
Prerequisites for this command
●
Turn off automatic scaling of the y-axis (DISPlay[:WINDow<n>]:TRACe<t>:
Y[:SCALe]:AUTO).
