11.7.3 Trace Configuration
● Trace Characteristics............................................................................................ 413
● Trace Copy............................................................................................................419
● Trace Export and Import....................................................................................... 419
● Trace Mathematics................................................................................................423
● Formats for Returned Values: ASCII Format and Binary Format..........................424
11.7.3.1 Trace Characteristics
Commands to configure traces described elsewhere.
●
DISPlay[:WINDow<n>]:TRACe<t>:SPURs:SUPPress
●
DISPlay[:WINDow<n>]:TRACe<t>:SPURs:THReshold
DISPlay[:WINDow<n>]:TRACe<t>:MODE.........................................................................413
DISPlay[:WINDow<n>]:TRACe<t>:LABel[:STATe]..............................................................414
DISPlay[:WINDow<n>]:TRACe<t>:LABel:TEXT.................................................................415
DISPlay[:WINDow<n>]:TRACe<t>:PERSistence:DECay.................................................... 415
DISPlay[:WINDow<n>]:TRACe<t>:PERSistence[:STATe]................................................... 415
DISPlay[:WINDow<n>]:TRACe<t>:RESult[:TYPE]............................................................. 416
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>[:STATe]............................................ 416
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:OFFSet........................................... 417
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:OFFSet:STATe................................. 417
DISPlay[:WINDow<n>]:TRACe<t>:SMOothing:APERture...................................................417
DISPlay[:WINDow<n>]:TRACe<t>:SMOothing[:STATe]...................................................... 418
DISPlay[:WINDow<n>]:TRACe<t>:MODE <Mode>
This command selects the trace mode. If necessary, the selected trace is also activa-
ted.
Suffix:
<n>
.
Window
<t> Trace
Parameters:
<Mode> WRITe
Overwrite mode: the trace is overwritten by each sweep. This is
the default setting.
Common Analysis and Display Functions
