Remote Control
R&S
®
FSPN
423User Manual 1179.4363.02 ─ 01
Example: //Import all compatible traces from an ASCII file into window 2
MMEM:LOAD2:TRAC 'c:\trace.dat'
Example: //Import all traces stored as window 1 into window 2
MMEM:LOAD2:TRAC 'c:\trace.dat',1
Example: //Import a single trace from ASCII file
MMEM:LOAD:TRAC 'c:\trace.dat',2,1,5
Manual operation: See "Select ASCII File" on page 161
See "Source Window / Source Trace" on page 161
See "Destination Trace" on page 162
See "Import" on page 162
11.7.3.4 Trace Mathematics
CALCulate<n>:MATH:STATe........................................................................................... 423
CALCulate<n>:MATH[:EXPRession][:DEFine]...................................................................423
CALCulate<n>:MATH:STATe <State>
This command turns trace mathematics on and off.
Suffix:
<n>
.
1..n
Window
Parameters:
<State> ON | 1
Turns trace mathematics on and selects the operation that has
been selected last (or (TRACE1-TRACE3) if you have not yet
selected one).
OFF | 0
Turns trace mathematics off.
*RST: OFF
Example: //Turn on trace 3, subtract it from trace 2 and write the result to
trace 2
DISP:TRAC3:MODE WRIT
CALC:MATH (TRACE2-TRACE3)
//Turn off trace mathematics
CALC:MATH:STAT OFF
//Turn them on again and selects the operation (TRACE2-
TRACE3).
CALC:MATH:STAT ON
Manual operation: See "Selecting the math operation" on page 163
CALCulate<n>:MATH[:EXPRession][:DEFine] <Operation>
This command selects the operation for trace mathematics.
Common Analysis and Display Functions
