Remote Control
R&S
®
FSPN
422User Manual 1179.4363.02 ─ 01
ALL
Selects all active traces and result tables (e.g. Result Summary,
marker peak list etc.) in the current application for export to an
ASCII file.
The <trace> parameter for the MMEMory:STORe<n>:TRACe
command is ignored.
*RST: SINGle
Manual operation: See " Export all Traces and all Table Results " on page 159
MMEMory:LOAD<n>:TRACe
<FileName>[, <Window>, <Trace>, <Trace>]
This commans imports a previously recorded trace.
Suffix:
<n>
.
1..n
Destination Window
Parameters:
<FileName> String that contains the location of the ASCII file you want to
import.
Supported file types are .dat and .csv.
<Window> <numeric value> (integer only)
Optional.
Selects the source window of the trace that you want to import.
Because the ASCII file can contain trace information for several
result windows, you can select a specfic result window whose
trace(s) are imported.
The selected window must be compatible to the destination win-
dows selected by the suffix at the LOAD<n> syntax element. For
example if you want to import the data of a phase noise trace, a
phase noise diagram must be active.
If you omit the source window, the R&S FSPN checks if the
import data is compatible to the diagram that you have selected.
If not, the command throws an error and the data is not impor-
ted.
Range:
1 to 16
<Trace> <numeric value> (integer only)
Optional.
Selects the number of the source trace. The source trace is the
trace you want to import.
Range: 1 to 6
<Trace> <numeric value> (integer only)
Optional.
Selects the number of the destination trace. The destination
trace is the trace you want to write the imported trace to.
Range: 1 to 6
Common Analysis and Display Functions
