Supported 89600 commands
:TRIGger[:SEQuence]:SOURce IMMediate|VIDeo|EXTernal<1|2>
:TRIGger[:SEQuence]:VIDeo:LEVel <numeric>
:TRIGger[:SEQuence]:VIDeo:LEVel:FREQuency <freq>
11.10 Using the Status Register
For more information on the contents of the status registers see:
●
"STATus:OPERation Register" on page 269
●
"STATus:QUEStionable:ACPLimit Register" on page 269
●
"STATus:QUEStionable:EXTended Register" on page 270
●
"STATus:QUEStionable:FREQuency Register" on page 271
●
"STATus:QUEStionable:LIMit Register" on page 272
●
"STATus:QUEStionable:LMARgin Register" on page 272
●
"STATus:QUEStionable:POWer Register" on page 273
●
"STATus:QUEStionable:TEMPerature Register" on page 274
●
"STATus:QUEStionable:TIMe Register" on page 274
● General Status Register Commands.................................................................... 515
● Reading Out the CONDition Part.......................................................................... 516
● Reading Out the EVENt Part.................................................................................516
● Controlling the ENABle Part..................................................................................517
● Controlling the Negative Transition Part............................................................... 518
● Controlling the Positive Transition Part................................................................. 518
11.10.1 General Status Register Commands
STATus:PRESet.............................................................................................................515
STATus:QUEue[:NEXT]?................................................................................................ 516
STATus:PRESet
This command resets the edge detectors and ENABle parts of all registers to a defined
value. All PTRansition parts are set to FFFFh, i.e. all transitions from 0 to 1 are
detected. All NTRansition parts are set to 0, i.e. a transition from 1 to 0 in a
CONDition bit is not detected. The ENABle part of the STATus:OPERation and
STATus:QUEStionable registers are set to 0, i.e. all events in these registers are not
passed on.
Usage:
Event
