7.2.2 Zoom Functions
Access: "Zoom" icons in toolbar
Single Zoom ...............................................................................................................149
Multi-Zoom ................................................................................................................. 149
Restore Original Display ............................................................................................ 149
Deactivating Zoom (Selection Mode) ......................................................................149
Single Zoom
A single zoom replaces the current diagram by a new diagram which displays an
enlarged extract of the trace. This function can be used repetitively until the required
details are visible.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe] on page 412
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:AREA on page 410
Multi-Zoom
In multiple zoom mode, you can enlarge several different areas of the trace simultane-
ously. An overview window indicates the zoom areas in the original trace, while the
zoomed trace areas are displayed in individual windows. The zoom area that corre-
sponds to the individual zoom display is indicated in the lower right corner, between the
scrollbars.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:MULTiple<zn>[:STATe]
on page 412
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:MULTiple<zn>:AREA
on page 411
Restore Original Display
Restores the original display, that is, the originally calculated displays for the entire
capture buffer, and closes all zoom windows.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe] on page 412
Deactivating Zoom (Selection Mode)
Deactivates any zoom mode.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe] on page 412
Zoomed Displays
