<x2> Diagram coordinates in % of the complete diagram that define
the zoom area.
The lower left corner is the origin of coordinate system. The
upper right corner is the end point of the system.
Range: 0 to 100
Default unit: PCT
<y2> Diagram coordinates in % of the complete diagram that define
the zoom area.
The lower left corner is the origin of coordinate system. The
upper right corner is the end point of the system.
Range: 0 to 100
Default unit: PCT
Manual operation: See " Multi-Zoom " on page 149
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:MULTiple<zn>[:STATe] <State>
This command turns the multiple zoom on and off.
Suffix:
<n>
.
Window
<w> subwindow
Not supported by all applications
<zn> Selects the zoom window.
If you turn off one of the zoom windows, all subsequent zoom
windows move up one position.
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
Manual operation: See " Multi-Zoom " on page 149
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe] <State>
This command turns the zoom on and off.
Suffix:
<n>
.
Window
<w> subwindow
Not supported by all applications
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
