R&S FSPN - Phase Noise Measurement Configuration

Remote Control
R&S
®
FSPN
360User Manual 1179.4363.02 ─ 01
[SENSe:]POWer:RLEVel:MODE <Level>
This command selects the level measurement mode.
Parameters:
<Level> HIGH
Use this mode to measure normal signal levels.
LOW
Use this mode to measure low signal levels.
When you select this mode, apply a low pass filter and define its
characteristics with:
•[SENSe:]FILTer:LPASs[:STATe]
•[SENSe:]FILTer:LPASs:FREQuency:MANual
*RST: HIGH
Example: //Measure low level signal
POW:RLEV:MODE LOW
Manual operation: See "Low signal levels" on page 109
[SENSe:]SWEep:CAPTure:RANGe <CaptureRange>
This command selects the signal capture range.
Parameters:
<CaptureRange> NORMal
Normal capture range for stable DUTs or DUTs whose frequency
drifts slowly over a short distance.
WIDE
Wide capture range for DUTs whose frequency drifts quickly and
over big distances.
R40Mhz
This setting is designed to work with carriers swept in -40 MHz
to +40 MHz around the center frequency. Additional spurs and
restrictions of the measurement accuracy are possible for CW
signals. For specifics of the measurement accuracy, refer to the
data sheet.
*RST:
NORMal
Example: //Select a wide signal capture range
SWE:CAPT:RANG WIDE
Manual operation: See "Capture Range" on page 108
11.6.6 Phase Noise Measurement Configuration
● Noise Configuration...............................................................................................361
● Residual Calculation Configuration.......................................................................368
● Spot Noise Configuration...................................................................................... 371
● Spur Display..........................................................................................................375
Common Measurement Settings
