Manual operation: See "Filtering spurs" on page 121
[SENSe:]SPURs:FILTer:LOAD <Filename>
This command loads an existing spurious filter configuration from a file.
Location of filter files: C:\R_S\instr\SpuriousFilter\
Setting parameters:
<Filename>
Example:
SENS:SPUR:FILT:LOAD "MyFile"
Usage: Setting only
Manual operation: See "Filtering spurs" on page 121
[SENSe:]SPURs:COLor
<Color>
Provides functionality to enable an automatic shift of the color of the displayed spurious
lines.
Parameters:
<Color> TRACe | SHIFted
Example:
SENS:SPUR:COL TRAC
Manual operation: See "Defining the spurious color" on page 121
11.6.7 VCO Characterization Configuration
● Sweep Configuration.............................................................................................379
11.6.7.1 Sweep Configuration
CONFigure:VCO:FIX:SOURce........................................................................................ 379
CONFigure:VCO:SWEep:DELay:INITial........................................................................... 380
CONFigure:VCO:SWEep:DELay[:POINt]..........................................................................380
CONFigure:VCO:SWEep:FCOunter:RESolution................................................................380
CONFigure:VCO:SWEep:POINts.....................................................................................381
CONFigure:VCO:SWEep:SOURce.................................................................................. 381
CONFigure:VCO:SWEep:STARt......................................................................................381
CONFigure:VCO:SWEep:STOP...................................................................................... 382
CONFigure:VCO:FIX:SOURce <PowerSource>
This command selects the DC source that is considered in the Current / Voltage result
display.
Parameters:
<PowerSource> VAUX
Selects the V
aux
connector.
