Remote Control
R&S
®
FSPN
381User Manual 1179.4363.02 ─ 01
Example: //Select a frequency resolution of 100 Hz.
CONF:VCO:SWE:FCO 100HZ
Manual operation: See "Selecting the frequency resolution" on page 129
CONFigure:VCO:SWEep:POINts <MeasPoints>
This command defines the number of measurement points for the VCO measurement.
Parameters:
<MeasPoints> <numeric value> (integer only)
*RST: 10
Example: See CONFigure:VCO:SWEep:SOURce.
Manual operation: See "Defining the sweep range" on page 128
CONFigure:VCO:SWEep:SOURce
<PowerSource>
This command selects the source (connector) which tunes the VCO.
Parameters:
<PowerSource> VAUX
Selects the V
aux
connector as the sweep source.
VSUPly
Selects the V
supply
connector as the sweep source.
VTUNe
Selects the V
tune
connector as the sweep source.
Example: //Select the V
supply
connector as the tuning source
CONF:VCO:SWE:SOUR VSUP
//Select the type of output at the V
supply
connector
SOUR:VOLT:POW:LEV:MODE VOLT
//Configure a tuning range with 10 measurement points
CONF:VCO:SWE:STAR 0V
CONF:VCO:SWE:STOP 5V
CONF:VCO:SWE:POIN 10
//Turn on the output of the tuning signal.
SOUR:VOLT:POW:LEV ON
CONFigure:VCO:SWEep:STARt <Value>
This command defines the start value of the tuning range.
Parameters:
<Value> <numeric value>
The unit depends on whether you tune the VCO with a voltage
or current (see CONFigure:VCO:SWEep:SOURce).
*RST: 0
Default unit: V or A
Common Measurement Settings
