Manual operation: See " Trace 1 / Trace 2 / Trace 3 / Trace 4 / Trace 5 / Trace 6 "
on page 156
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:OFFSet <Offset>
This command defines the amount by which a trace is shifted.
Prerequisites for this command
●
Turn on trace offset (DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:
OFFSet:STATe).
Suffix:
<n>
.
1..n
irrelevant
<t> 1..n
irrelevant
Parameters:
<Offset> <numeric value>
*RST: 0
Default unit: dB
Example: //Define a level offset of 10 dB
DISP:TRAC:Y:RLEV:OFFS 10
Manual operation: See "Shifting the trace" on page 157
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:OFFSet:STATe <State>
This command turns the offset for a trace on and off.
When you turn that feature on, the trace is shifted vertically by a certain amount.
Suffix:
<n>
.
1..n
Window
<t> 1..n
Trace
Parameters:
<State> ON | OFF | 1 | 0
*RST: OFF
Example: //Shift trace 2 vertically by 10 dB.
DISP:TRAC2:Y:RLEV:OFFS:STAT ON
DISP:TRAC2:Y:RLEV:OFFS 10
Manual operation: See "Shifting the trace" on page 157
DISPlay[:WINDow<n>]:TRACe<t>:SMOothing:APERture <Aperture>
This command defines the magnitude (aperture) of trace smoothing.
