Prerequisites for this command
●
Turn on trace smoothing (DISPlay[:WINDow<n>]:TRACe<t>:SMOothing[:
STATe]).
Suffix:
<n>
.
1..n
Window
<t> 1..n
Trace
Parameters:
<Aperture> <numeric value>
Range: 1 to 20
*RST: 1
Default unit: PCT
Example: See DISPlay[:WINDow<n>]:TRACe<t>:SMOothing[:
STATe].
Manual operation: See "Smoothing traces" on page 157
DISPlay[:WINDow<n>]:TRACe<t>:SMOothing[:STATe] <State>
This command turns trace smoothing for a specific trace on and off.
When you turn on trace smoothing, you can define the smoothing magnitude with
DISPlay[:WINDow<n>]:TRACe<t>:SMOothing:APERture.
Suffix:
<n>
.
1..n
Window
<t> 1..n
Trace
Parameters:
<State> ON | OFF | 1 | 0
*RST: Depends on the trace.
Example: //Turns on trace 3 (average mode based on 10 measurements)
to display the AM noise results
DISP:TRAC3:MODE AVER
SWE:COUN 10
DISP:TRAC3:RES AM
//Smooth the trace by a magnitude of 10 %
DISP:TRAC3:SMO ON
DISP:TRAC3:SMO:APER 10
//Remove spurs from trace 3
DISP:TRAC3:SPUR:SUPP ON
DISP:TRAC3:SPUR:THR 5
Manual operation: See "Smoothing traces" on page 157
