Remote Control
R&S
®
FSPN
415User Manual 1179.4363.02 ─ 01
Example: //Turn on the label for trace 2
DISP:TRAC2:LAB ON
DISPlay[:WINDow<n>]:TRACe<t>:LABel:TEXT <Label>
This command defines the contents of a trace label.
Suffix:
<n>
.
1..n
Window
<t> 1..n
Trace
Parameters:
<Label> String containing the trace label.
Example: //Assign a label to trace 2.
DISP:TRAC2:LAB:TEXT 'A YELLOW TRACE'
DISPlay[:WINDow<n>]:TRACe<t>:PERSistence:DECay <Decay>
This command defines the time period that an event remains visible until it fades away
(decay).
Prerequisites for this command
●
Turn on persistence (DISPlay[:WINDow<n>]:TRACe<t>:PERSistence[:
STATe]).
Suffix:
<n>
.
1..n
Window
<t> 1..n
Trace
Parameters:
<Decay> <numeric value>
Range: 0 s to 8 s
*RST: 0
Default unit: s
Example: //Turn on persistence for trace 2 with a decay of 2 seconds
DISP:TRAC2:PERS ON
DISP:TRAC2:PERS:DEC 2s
Manual operation: See "Displaying persistence" on page 157
DISPlay[:WINDow<n>]:TRACe<t>:PERSistence[:STATe] <State>
This command turns persistence for a trace on and off.
Common Analysis and Display Functions
