Parameters:
<Unit> DBM_hz | DBV_hz | DBUV_hz | HZ | DEG | RAD | V_SQRT_HZ
*RST: DBM_hz
Example: //Display the baseband noise results in the unit dBV/Hz.
DISP:TRAC:Y:UNIT DBV
Manual operation: See "Selecting the unit of the y-axis" on page 105
INPut<1|2>:ATTenuation <Attenuation>
This command defines the RF attenuation for the RF input.
Prerequisites for this command
●
Turn off automatic attenuation configuration (INPut<1|2>:ATTenuation:AUTO).
Suffix:
<1|2>
.
1|2
irrelevant
Parameters:
<Attenuation> <numeric value> (integer only)
Range: See data sheet
Increment: 5
Default unit: dB
Example: //Defines an attenuation of 10 dB
INP:ATT:AUTO OFF
INP:ATT 10
Manual operation: See "Attenuating the signal" on page 103
INPut<1|2>:ATTenuation:AUTO <State>
This command turns automatic configuration of the attenuation on and off.
Suffix:
<1|2>
.
1|2
irrelevant
Parameters:
<State> ON | 1
Automatically defines the ideal attenuation based on the current
signal level.
OFF | 0
Allows you to define the attenuation manually with
INPut<1|2>:ATTenuation
*RST: ON
Example: //Turn on automatic configuration of the attenuation
INP:ATT:AUTO ON
Manual operation: See "Attenuating the signal" on page 103
