Trace color Color of trace display in diagram
Trace number Number of the trace (1 to 6)
Trace Mode
Abbreviation of the trace mode:
●
Clrw
Clear Write trace
●
Max
Max Hold trace
●
Min
Min Hold trace
●
Avg
Average trace
●
View
Frozen trace
●
WrH
Write Hold trace
Result type
Type of result the trace represents.
●
PN
●
AM
●
PN + AM
Trace smoothing Trace smoothing characteristics. Only displayed if trace smoothing has been
turned on for a trace.
Spur removal Spur removal characteristics. Only displayed if spur removal has been turned
on for a trace.
Trace offset Trace offset characteristics. Only displayed if an offset has been defined for a
trace.
3.3.1.3 Marker Information
Marker information is provided either in the diagram grid or in separate marker tables,
depending on the configuration.
Marker information in diagram grid
Within the diagram, the x-axis and y-axis positions of the last 2 markers or delta mark-
ers that were set are displayed, if available, as well as their index. The value in the
square brackets after the index indicates the trace to which the marker is assigned.
(Example: M2[1] defines marker 2 on trace 1.) For more than 2 markers, a separate
marker table is displayed beneath the diagram by default.
Marker information in marker table
In addition to the marker information displayed within the diagram grid, separate
marker tables may be added to the display. These tables provide the following informa-
tion for all active markers:
Table 3-4: Regular marker table
Label Information
Wnd Window type the marker is positioned in.
(Only if there is more than one window containing a phase noise diagram.)
Type Marker type: N (normal), D (delta), T (temporary, internal)
