Rev. 7.00 Mar 10, 2005 page xii of xlii
Item Page Revision (See Manual for Details)
3.3.2 Interrupt
Control Registers
Interrupt Request
Register 2 (IRR2)
Bit 1
88 Table amended
Setting conditions:
When the timer C counter value overflows or underflows
4.2 System Clock
Generator
Connecting a Ceramic
Oscillator
Figure 4.5(2) Typical
Connection to
Ceramic Oscillator
(H8/38024S,
H8/38124 Group)
108 Table and notes amended
Frequency
2.0 MHz
10.0 MHz
16.0 MHz
*
1
20.0 MHz
*
2
Murata
Ceramic
oscillator
Products name
CSTCC2M00G53-B0
CSTCC2M00G56-B0
CSTLS10M0G53-B0
CSTLS10M0G56-B0
CSTLS16M0X53-B0
CSTLS20M0X53-B0
15 pF ±20%
47 pF ±20%
15 pF ±20%
47 pF ±20%
15 pF ±20%
15 pF ±20%
C
1
, C
2
Recommendation
value
Notes: Circuit constants should be determined in consultation
with the resonator manufacturer.
1. This does not apply to the H8/38024S Group.
2. H8/38124 Group only
Notes on Board
Design
Figure 4.6 Board
Design of Oscillator
Circuit
109 Figure amended
OSC
OSC
C
1
C
2
Signal A Signal B
2
1
To be avoided
××
4.6 Notes on
H8/38124 Group
118 Description amended
Consequently, even if the on-chip oscillator is selected when
using the on-chip emulator, pins OSC1 and OSC2 should be
connected to an oscillator, or an external clock should be
supplied.
5.1 Overview
Table 5.1 Operating
Modes
119 Table amended
Operating Mode Description
Subactive mode
The CPU and all on-chip peripheral functions are operable on
the subclock in low-speed operation
