Item Page Revision (See Manual for Details)
7.1 Overview 191 Note deleted
8.2.2 Register
Configuration and
Description
Port Data Register 1
(PDR1)
196 Note amended
Note: * Pin 1
6
and the associated function are not
implemented on the H8/38124 Group.
The register is both
readable and writeable.
Port Pull-Up Control
Register 1 (PUCR1)
197 Note amended
Note: * Pin 1
6
and the associated function are not
implemented on the H8/38124 Group. The register is both
readable and writeable.
8.9.3 Pin Functions
Table 8.24 Port 9 Pin
Functions
232 Table amended
Pin Pin Functions and Selection Method
P9
3
/V
ref
*
VREFSEL 0 1
Pin function P9
3
output pin V
ref
input pin
9.2.1 Overview 246 Description amended
Timer A is an 8-bit timer with interval timing and real-time clock
time-base functions. The clock time-base function is available
when a 32.768 kHz crystal oscillator is connected as the
subclock.
• Choice of four overflow periods (1 s, 0.5 s, 0.25 s, 31.25 ms)
when timer A is used as a clock time base (using a 32.768 kHz
crystal oscillator is connected as the subclock).
9.4.3 CPU Interface 271 Description amended
When performing TCF read/write access or OCRF write access
in 16-bit mode, data will not be transferred correctly if only the
upper byte or only the lower byte is accessed. Access must be
performed for all 16 bits (using two consecutive byte-size MOV
instructions), and the upper byte must be accessed before the
lower byte.
9.5.2 Register
Descriptions
Timer Mode Register
G (TMG)
Bit 7
Bit 6
285 Table amended
Setting condition:
Set when input capture input signal is high level and TCG
overflows from H'FF to H'00
Setting condition:
Set when TCG overflows from H'FF to H'00 while input capture
input signal is high level or during interval operation
