Section 6 ROM
Rev. 7.00 Mar 10, 2005 page 171 of 652
REJ09B0042-0700
Table 6.10 Reprogram Data Computation Table
Program Data Verify Data Reprogram Data Comments
0 0 1 Programming completed
0 1 0 Reprogram bit
101 —
1 1 1 Remains in erased state
Table 6.11 Additional-Program Data Computation Table
Reprogram Data Verify Data
Additional-Program
Data Comments
0 0 0 Additional-program bit
0 1 1 No additional programming
1 0 1 No additional programming
1 1 1 No additional programming
Table 6.12 Programming Time
n
(Number of Writes)
Programming
Time
In Additional
Programming Comments
1 to 6 30 10
7 to 1,000 200 —
Note: Time shown in µs.
