Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 318 of 652
REJ09B0042-0700
Bits 5 and 4—AEC Clock Select L (ACKL1, ACKL0)
Bits 5 and 4 select the clock used by ECL.
Bit 5
ACKL1
Bit 4
ACKL0 Description
0 0 AEVL pin input (initial value)
1 φ/2
10φ/4
1 φ/8
Bits 3 to 1—Event Counter PWM Clock Select (PWCK2, PWCK1, PWCK0)
Bits 3 to 1 select the event counter PWM clock.
Bit 3
PWCK2
Bit 2
PWCK1
Bit 1
PWCK0 Description
000φ/2 (initial value)
1 φ/4
10φ/8
1 φ/16
1 * 0 φ/32
1 φ/64
*: Don’t care
Bit 0—Reserved
Bit 0 is a readable/writable reserved bit. It is initialized to 0 by a reset.
Note: Do not set this bit to 1.
