Section 16 Electrical Characteristics
Rev. 7.00 Mar 10, 2005 page 517 of 652
REJ09B0042-0700
Values
Item Symbol
Applicable
Pins Min Typ Max Unit
Test
Condition Notes
Allowable output low
current (per pin)
I
OL
Output pins
except ports 3
and 9
——2.0mAV
CC
= 4.0 V to
5.5 V
Port 3 ——10.0 V
CC
= 4.0 V to
5.5 V
Output pins
except port 9
——0.5
Port 9 ——15.0 V
CC
= 4.0 V to
5.5 V
——5.0
Other than
above
Allowable output low
current (total)
∑ I
OL
Output pins
except ports 3
and 9
——40.0mAV
CC
= 4.0 V to
5.5 V
Port 3 ——80.0
V
CC
= 4.0 V to
5.5 V
Output pins
except port 9
——20.0
Port 9 ——80.0
–I
OH
All output pins — — 2.0 mA V
CC
= 4.0 V to
5.5 V
Allowable output high
current (per pin)
— — 0.2 Other than
above
∑ –I
OH
All output pins — — 15.0 mA
V
CC
= 4.0 V to
5.5 V
Allowable output high
current (total)
— — 10.0 Other than
above
Notes: Connect the TEST pin to V
SS
.
1. Applies to the mask-ROM version.
2. Applies to the F-ZTAT version.
