3. Pin states when current consumption is measured
Mode
RES
Pin Internal State Other Pins
LCD Power
Supply Oscillator Pins
Active (high-speed)
mode (I
OPE1
)
Active (medium-
speed) mode (I
OPE2
)
V
CC
Only CPU operates V
CC
Stops
Sleep mode V
CC
Only all on-chip timers
operate
V
CC
Stops
System clock:
crystal resonator
Subclock:
Pin X
1
= GND
Subactive mode V
CC
Only CPU operates V
CC
Stops
Subsleep mode V
CC
Only all on-chip timers
operate
CPU stops
V
CC
Stops
Watch mode V
CC
Only clock time base
operates
CPU stops
V
CC
Stops
System clock:
crystal resonator
Subclock:
crystal resonator
Standby mode V
CC
CPU and timers
both stop
V
CC
Stops System clock:
crystal resonator
Subclock:
Pin X
1
= GND
4. Except current which flows to the pull-up MOS or output buffer
5. Used when user mode or boot mode is determined after canceling a reset in the F-
ZTAT version
6. Voltage maintained in standby mode
