Appendix A CPU Instruction Set
Rev. 7.00 Mar 10, 2005 page 542 of 652
REJ09B0042-0700
Mnemonic Operation I H N Z V C
JSR @Rn  SP−2 → SP 2  6
PC → @SP
PC ← Rn16
JSR @aa:16  SP−2 → SP 4  8
PC → @SP
PC ← aa:16
JSR @@aa:8 SP−2 → SP 2  8
PC → @SP
PC ← @aa:8
RTS 

PC ← @SP 2  8
SP+2 → SP
RTE  CCR ← @SP 2
↔ ↔ ↔ ↔ ↔ ↔
↔ ↔ ↔ ↔ ↔ ↔
↔ ↔ ↔ ↔ ↔ ↔
↔ ↔ ↔ ↔ ↔ ↔
↔ ↔ ↔ ↔ ↔ ↔
↔ ↔ ↔ ↔ ↔ ↔
10
SP+2 → SP
PC ← @SP
SP+2 → SP
SLEEP  Transit to sleep mode. 2  2
LDC #xx:8, CCR B #xx:8 → CCR 2 2
LDC Rs, CCR B Rs8 → CCR 2 2
STC CCR, Rd B CCR → Rd8 2  2
ANDC #xx:8, CCR B CCR∧#xx:8 → CCR 2 2
ORC #xx:8, CCR B CCR∨#xx:8 → CCR 2 2
XORC #xx:8, CCR B CCR⊕#xx:8 → CCR 2 2
NOP  PC ← PC+2 2  2
EEPMOV  if R4L≠04(4)
Repeat @R5 → @R6
R5+1 → R5
R6+1 → R6
R4L−1 → R4L
Until R4L=0
else next;
Notes: (1) Set to 1 when there is a carry or borrow from bit 11; otherwise cleared to 0.
(2) If the result is zero, the previous value of the flag is retained; otherwise the flag is cleared to 0.
(3) Set to 1 if decimal adjustment produces a carry; otherwise retains value prior to arithmetic operation.
(4) The number of states required for execution is 4n + 9 (n = value of R4L). 4n + 8 for HD64F38024,
H8/38024S Group, and H8/38124 Group.
(5) Set to 1 if the divisor is negative; otherwise cleared to 0.
(6) Set to 1 if the divisor is zero; otherwise cleared to 0.
