Renesas H8 Series Hardware Manual

Appendix B Internal I/O Registers
Rev. 7.00 Mar 10, 2005 page 551 of 652
REJ09B0042-0700
Upper Address: H'FF
Bit Names
Lower
Address
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Module Name
H'80
H'81
H'82
H'83
H'84
H'85
H'86 LVDCR LVDE — VINTDSEL VINTUSEL LVDSL LVDRE LVDDE LVDUE
H'87LVDSROVF———VREFSEL—LVDDFLVDUF
Low-voltage
detect circuit
*
H'88
H'89
H'8A
H'8B
H'8C ECPWCRH ECPWCRH7 ECPWCRH6 ECPWCRH5 ECPWCRH4 ECPWCRH3 ECPWCRH2 ECPWCRH1 ECPWCRH0 Asynchronous
H'8D ECPWCRL ECPWCRL7 ECPWCRL6 ECPWCRL5 ECPWCRL4 ECPWCRL3 ECPWCRL2 ECPWCRL1 ECPWCRL0 event counter
H'8E ECPWDRH ECPWDRH7 ECPWDRH6 ECPWDRH5 ECPWDRH4 ECPWDRH3 ECPWDRH2 ECPWDRH1 ECPWDRH0
H'8F ECPWDRL ECPWDRL7 ECPWDRL6 ECPWDRL5 ECPWDRL4 ECPWDRL3 ECPWDRL2 ECPWDRL1 ECPWDRL0
H'90 WEGR WKEGS7 WKEGS6 WKEGS5 WKEGS4 WKEGS3 WKEGS2 WKEGS1 WKEGS0 System control
H'91 SPCR — — SPC32 — SCINV3 SCINV2 — — SCI3
H'92 AEGSR AHEGS1 AHEGS0 ALEGS1 ALEGS0 AIEGS1 AIEGS0 ECPWME — Asynchronous
H'93 event counter
H'94 ECCR ACKH1 ACKH0 ACKL1 ACKL0 PWCK2 PWCK1 PWCK0 —
H'95 ECCSR OVH OVL — CH2 CUEH CUEL CRCH CRCL
H'96 ECH ECH7 ECH6 ECH5 ECH4 ECH3 ECH2 ECH1 ECH0
H'97 ECL ECL7 ECL6 ECL5 ECL4 ECL3 ECL2 ECL1 ECL0
H'98
H'99
H'9A
H'9B
H'9C
H'9D
H'9E
H'9F
