Appendix B Internal I/O Registers

Rev. 7.00 Mar 10, 2005 page 552 of 652

REJ09B0042-0700

Upper Address: H'FF

Bit Names

Lower

Address

Name

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Module Name

H'A0

H'A1

H'A2

H'A3

H'A4

H'A5

H'A6

H'A7

H'A8 SMR COM CHR PE PM STOP MP CKS1 CKS0 SCI3

H'A9 BRR BRR7 BRR6 BRR5 BRR4 BRR3 BRR2 BRR1 BRR0

H'AA SCR3 TIE RIE TE RE MPIE TEIE CKE1 CKE0

H'AB TDR TDR7 TDR6 TDR5 TDR4 TDR3 TDR2 TDR1 TDR0

H'AC SSR TDRE RDRF OER FER PER TEND MPBR MPBT

H''AD RDR RDR7 RDR6 RDR5 RDR4 RDR3 RDR2 RDR1 RDR0

H'AE

H'AF

H'B0TMA————TMA3TMA2TMA1TMA0Timer A

H'B1 TCA TCA7 TCA6 TCA5 TCA4 TCA3 TCA2 TCA1 TCA0

H'B2 TCSRW B6WI TCWE B4WI TCSRWE B2WI WDON BOWI WRST Watchdog

H'B3 TCW TCW7 TCW6 TCW5 TCW4 TCW3 TCW2 TCW1 TCW0 timer

H'B4 TMC TMC7 TMC6 TMC5 _ _ TMC2 TMC1 TMC0 Timer C

H'B5 TCC/TLC TCC7/TLC7 TCC6/TLC6 TCC5/TLC5 TCC4/TLC4 TCC3/TLC3 TCC2/TLC2 TCC1/TLC1 TCC0/TLC0

H'B6 TCRF TOLH CKSH2 CKSH1 CKSH0 TOLL CKSL2 CKSL1 CKSL0 Timer F

H'B7 TCSRF OVFH CMFH OVIEH CCLRH OVFL CMFL OVIEL CCLRL

H'B8 TCFH TCFH7 TCFH6 TCFH5 TCFH4 TCFH3 TCFH2 TCFH1 TCFH0

H'B9 TCFL TCFL7 TCFL6 TCFL5 TCFL4 TCFL3 TCFL2 TCFL1 TCFL0

H'BA OCRFH OCRFH7 OCRFH6 OCRFH5 OCRFH4 OCRFH3 OCRFH2 OCRFH1 OCRFH0

H'BB OCRFL OCRFL7 OCRFL6 OCRFL5 OCRFL4 OCRFL3 OCRFL2 OCRFL1 OCRFL0

H'BC TMG OVFH OVFL OVIE IIEGS CCLR1 CCLR0 CKS1 CKS0 Timer G

H'BD ICRGF ICRGF7 ICRGF6 ICRGF5 ICRGF4 ICRGF3 ICRGF2 ICRGF1 ICRGF0

H'BE ICRGR ICRGR7 ICRGR6 ICRGR5 ICRGR4 ICRGR3 ICRGR2 ICRGR1 ICRGR0

H'BF
