Appendix B Internal I/O Registers
Rev. 7.00 Mar 10, 2005 page 553 of 652
REJ09B0042-0700
Upper Address: H'FF
Bit Names
Lower
Address
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Module Name
H'C0 LPCR DTS1 DTS0 CMX — SGS3 SGS2 SGS1 SGS0
H'C1 LCR — PSW ACT DISP CKS3 CKS2 CKS1 CKS0
H'C2 LCR2 LCDAB — — — CDS3
*
CDS2
*
CDS1
*
CDS0
*
LCD controller/
driver
H'C3 LVDCNT CNT7 CNT6 CNT5 CNT4 CNT3 CNT2 CNT1 CNT0 Low-voltage
detect circuit
*
H'C4 ADRRH ADR9 ADR8 ADR7 ADR6 ADR5 ADR4 ADR3 ADR2 A/D converter
H'C5 ADRRL ADR1 ADR0 ——————
H'C6 AMR CKS TRGE — — CH3 CH2 CH1 CH0
H'C7ADSRADSF———————
H'C8 PMR1 IRQ3 — — IRQ4 TMIG — — — I/O port
H'C9 PMR2 — — POF1 — — WDCKS NCS IRQ0
H'CA PMR3 AEVL AEVH ———TMOFHTMOFLUD
H'CB
H'CC PMR5 WKP7 WKP6 WKP5 WKP4 WKP3 WKP2 WKP1 WKP0
H'CDPWCR2—————PWCR22
*
PWCR21 PWCR20 10 bit PWM2
H'CE PWDRU2 ——————PWDRU21 PWDRU20
H'CF PWDRL2 PWDRL27 PWDRL26 PWDRL25 PWDRL24 PWDRL23 PWDRL22 PWDRL21 PWDRL20
H'D0PWCR1—————PWCR12
*
PWCR11 PWCR10 10 bit PWM1
H'D1 PWDRU1 ——————PWDRU11 PWDRU10
H'D2 PWDRL1 PWDRL17 PWDRL16 PWDRL15 PWDRL14 PWDRL13 PWDRL12 PWDRL11 PWDRL10
H'D3
H'D4 PDR1 P17 P16 — P14 P13 — — — I/O port
H'D5
H'D6 PDR3 P37 P36 P35 P34 P33 P32 P31 P30
H'D7PDR4————P43P42P41P40
H'D8 PDR5 P57 P56 P55 P54 P53 P52 P51 P50
H'D9 PDR6 P67 P66 P65 P64 P63 P62 P61 P60
H'DA PDR7 P77 P76 P75 P74 P73 P72 P71 P70
H'DB PDR8 P87 P86 P85 P84 P83 P82 P81 P80
H'DC PDR9 — — P95 P94 P93 P92 P91 P90
H'DDPDRA————PA3PA2PA1PA0
H'DE PDRB PB7 PB6 PB5 PB4 PB3 PB2 PB1 PB0
H'DF
