Renesas H8 Series

Appendix B Internal I/O Registers
Rev. 7.00 Mar 10, 2005 page 554 of 652
REJ09B0042-0700
Upper Address: H'FF
Bit Names
Lower
Address
Register
Name
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Module Name
H'E0 PUCR1 PUCR17 PUCR16 — PUCR14 PUCR13 — — — I/O port
H'E1 PUCR3 PUCR37 PUCR36 PUCR35 PUCR34 PUCR33 PUCR32 PUCR31 PUCR30
H'E2 PUCR5 PUCR57 PUCR56 PUCR55 PUCR54 PUCR53 PUCR52 PUCR51 PUCR50
H'E3 PUCR6 PUCR67 PUCR66 PUCR65 PUCR64 PUCR63 PUCR62 PUCR61 PUCR60
H'E4 PCR1 PCR17 PCR16 — PCR14 PCR13 — — —
H'E5
H'E6 PCR3 PCR37 PCR36 PCR35 PCR34 PCR33 PCR32 PCR31 PCR30
H'E7PCR4—————PCR42PCR41PCR40
H'E8 PCR5 PCR57 PCR56 PCR55 PCR54 PCR53 PCR52 PCR51 PCR50
H'E9 PCR6 PCR67 PCR66 PCR65 PCR64 PCR63 PCR62 PCR61 PCR60
H'EA PCR7 PCR77 PCR76 PCR75 PCR74 PCR73 PCR72 PCR71 PCR70
H'EB PCR8 PCR87 PCR86 PCR85 PCR84 PCR83 PCR82 PCR81 PCR80
H'ECPMR9————PIOFF—PWM2PWM1
H'EDPCRA————PCRA3PCRA2PCRA1PCRA0
H'EEPMRB————IRQ1———
H'EF
H'F0 SYSCR1 SSBY STS2 STS1 STS0 LSON — MA1 MA0 System control
H'F1SYSCR2———NESEL DTON MSON SA1 SA0
H'F2IEGR———IEG4IEG3—IEG1IEG0
H'F3 IENR1 IENTA — IENWP IEN4 IEN3 IENEC2 IEN1 IEN0
H'F4 IENR2 IENDT IENAD — IENTG IENTFH IENTFL IENTC IENEC
H'F5 OSCCR
*
SUBSTP————IRQAECFOSCF—
H'F6 IRR1 IRRTA — — IRRI4 IRRI3 IRREC2 IRRI1 IRRI0
H'F7 IRR2 IRRDT IRRAD — IRRTG IRRTFH IRRTFL IRRTC IRREC
H'F8 TMW
*
————CKS3CKS2CKS1CKS0
Watchdog
timer
H'F9 IWPR IWPF7 IWPF6 IWPF5 IWPF4 IWPF3 IWPF2 IWPF1 IWPF0 System control
H'FA CKSTPR1 — — S32CKSTP ADCKSTP TGCKSTP TFCKSTP TCCKSTP TACKSTP
H'FBCKSTPR2———PW2CKSTPAECKSTPWDCKSTPPW1CKSTPLDCKSTP
H'FC
H'FD
H'FE
H'FF
[Legend]
SCI: Serial Communication Interface
Note: * H8/38124 only
