Renesas H8 Series Hardware Manual

Section 1 Overview
Rev. 7.00 Mar 10, 2005 page 18 of 652
REJ09B0042-0700
Table 1.4 Bonding Pad Coordinates of HCD64338024S, HCD64338023S, HCD64338022S,
HCD64338021S, and HCD64338020S
Coordinates Coordinates
Pad No. Pad Name X (µ
µµ
µm) Y (µ
µµ
µm) Pad No. Pad Name X (µ
µµ
µm) Y (µ
µµ
µm)
1AV
CC
–1338 1053 41 P84/SEG29 1338 –1121
2 P13/TMIG –1338 823 42 P85/SEG30 1338 –929
3 P14/ IRQ4 / ADTRG –1338 737 43 P86/SEG31 1338 –820
4 P16 –1338 649 44 P87/SEG32 1338 –721
5 P17/ IRQ3 /TMIF –1338 556 45 PA3/COM4 1338 –610
6 X1 –1338 460 46 PA2/COM3 1338 –499
7 X2 –1338 363 47 PA1/COM2 1338 –388
8V
SS
= AV
SS
–1338 229 48 PA0/COM1 1338 –277
9 OSC2 –1338 100 49 V3 1338 –189
10 OSC1 –1338 13 50 V2 1338 –91
11 TEST –1338 –74 51 V1 1338 6
12 RES –1338 –168 52 V
CC
1338 156
13 P50/ WKP0 /SEG1 –1338 –265 53 V
SS
1338 362
14 P51/ WKP1 /SEG2 –1338 –373 54 P90/PWM1 1338 528
15 P52/ WKP2 /SEG3 –1338 –481 55 P91/PWM2 1338 614
16 P53/ WKP3 /SEG4 –1338 –590 56 P92 1338 699
17 P54/ WKP4 /SEG5 –1338 –698 57 P93 1338 785
18 P55/ WKP5 /SEG6 –1338 –806 58 P94 1338 871
19 P56/ WKP6 /SEG7 –1338 –892 59 P95 1338 957
20 P57/ WKP7 /SEG8 –1338 –1091 60 IRQAEC 1338 1147
21 P60/SEG9 –1121 –1338 61 P30/UD 1131 1338
22 P61/SEG10 –927 –1338 62 P31/TMOFL 936 1338
23 P62/SEG11 –805 –1338 63 P32/TMOFH 831 1338
24 P63/SEG12 –703 –1338 64 P33 735 1338
25 P64/SEG13 –593 –1338 65 P34 631 1338
26 P65/SEG14 –483 –1338 66 P35 526 1338
27 P66/SEG15 –372 –1338 67 P36/AEVH 421 1338
28 P67/SEG16 –263 –1338 68 P37/AEVL 317 1338
29 P70/SEG17 –166 –1338 69 P40/SCK32 212 1338
30 P71/SEG18 –47 –1338 70 P41/RXD32 108 1338
31 P72/SEG19 55 –1338 71 P42/TXD32 3 1338
32 P73/SEG20 166 –1338 72 P43/ IRQ0 –101 1338
33 P74/SEG21 277 –1338 73 PB0/AN0 –249 1338
34 P75/SEG22 388 –1338 74 PB1/AN1 –362 1338
35 P76/SEG23 499 –1338 75 PB2/AN2 –476 1338
36 P77/SEG24 610 –1338 76 PB3/AN3/ IRQ1 /TMIC –589 1338
37 P80/SEG25 701 –1338 77 PB4/AN4 –702 1338
38 P81/SEG26 790 –1338 78 PB5/AN5 –791 1338
39 P82/SEG27 885 –1338 79 PB6/AN6 –880 1338
40 P83/SEG28 1076 –1338 80 PB7/AN7 –1081 1338
Note: Pad No. 11 (TEST) should be connected to V
SS
.
If it is not connected, the LSI will not operate correctly.
These values show the coordinates of the centers of pads. The accuracy is ±5 µm.
The home-point position is the chip’s center and the center is located at halfway between the upper and lower pads and
the left and right pads.
