Appendix B Internal I/O Registers
Rev. 7.00 Mar 10, 2005 page 583 of 652
REJ09B0042-0700
ICRGF—Input Capture Register GF H'BD Timer G
Bit
Initial value
Read/Write
7
ICRGF7
0
R
6
ICRGF6
0
R
5
ICRGF5
0
R
3
ICRGF3
0
R
0
ICRGF0
0
R
2
ICRGF2
0
R
1
ICRGF1
0
R
4
ICRGF4
0
R
Stores TCG value at falling edge of input capture signal
ICRGR—Input Capture Register GR H'BE Timer G
Bit
Initial value
Read/Write
7
ICRGR7
0
R
6
ICRGR6
0
R
5
ICRGR5
0
R
3
ICRGR3
0
R
0
ICRGR0
0
R
2
ICRGR2
0
R
1
ICRGR1
0
R
4
ICRGR4
0
R
Stores TCG value at rising edge of input capture signal
