Renesas H8 Series Hardware Manual

Appendix G Specifications of Chip Form
Rev. 7.00 Mar 10, 2005 page 648 of 652
REJ09B0042-0700
X-direction: 2.91 ± 0.05
Y-direction: 2.91 ± 0.05
Maximum plain X-direction: 2.91 ± 0.25
Y-direction: 2.91 ± 0.25
0.28 ± 0.02
Max 0.03
Unit: mm
Figure G.3 Chip Sectional Figure of the HCD64338024S, HCD64338023S, HCD64338022S,
HCD64338021S, and HCD64338020S
