Appendix I Specifications of Chip Tray
Rev. 7.00 Mar 10, 2005 page 651 of 652
REJ09B0042-0700
Chip direction
Chip
Type name
Chip tray name
DAINIPPON-INK-&-CHEMICALS-INC.
Type: CT015
Carved code: TCT45-060P
X-X' cross section
Unit: mm
0.6 ± 0.1
6.2 ± 0.16.9 ± 0.14.0 ± 0.1
6.2 ± 0.1 6.9 ± 0.1
XX'
4.24
3.84
51
51
4.5 ± 0.05
1.8 ± 0.1
4.5 ± 0.05
Figure I.2 Specifications of Chip Tray for the HCD64F38024 and HCD64F38024R
