ECODRIVE03 Drive Controllers ECODRIVE03 Auxiliary Capacitance Module CZM01.3 7-3
Materials used, Mass
3.10MZCtinUlobmySnoitangiseD
5gkmssaM
eerf enocilis dna sotsebsa--desu slairetaM
Fig. 7-2: Materials used, Mass
Ambient and operating conditions
See page 4-4: "Ambient and operating conditions"
Electrical Data of Auxiliary Component CZM01.3
Power section
3.10MZCtinUlobmySnoitangiseD
nominal DC bus capacity C
ZW
4.2Fm
Nom. discharge time constant
Ï„
34s
Storable energy of the DC bus
capacitors
W
ZW,CZM
Ws See "Fig. 7-4: Storable energy in the DC bus
for CZM01.3"
Allowed input voltage at L+, L- at
X5
U
ZW
V DC bus voltage ECODRIVE
DC (300 ... 800)
Device power dissipation P
V
05W
Uegatlov tupni sniaM
N
.c.nV
Cooling natural convection
Insulation resistance at DC500V R
is
52 >mhOM
Fig. 7-3: Technical data CZM01.3
See also page 16-4 CZM01.3
Note: The higher the connection voltage the lower the energy that
can be stored in the DC bus as the dierential voltage
between bleeder threshold and DC bus voltage (threshold
value of connecting voltage) decreases.
