4.3 Electrical Connections – dependent on the drive
controller type
DKC 01.3-***-7-FW – Parallel Interface
View of interface to command communications
FA5032F1.FH7
14
1
25
13
X15:
Parallel Interface
(female, 25 pins)
X15
Fig. 4-159: View of interface to command communications
Technical description of connector
Type No. of pins Design
D-SUB 25 Bushing on the unit
Fig. 4-160: Design
Cross sections
single wire
[mm ²]
Cross sections
multi core wire
[mm ²]
Cross sections
in AWG
gauge no.:
-- 0.08-0.5 --
Fig. 4-161: Connection cross sections
Design:
Connection cross section:
