7-4 ECODRIVE03 Auxiliary Capacitance Module CZM01.3 ECODRIVE03 Drive Controllers
0
100
200
300
400
500
600
700
800
0 100 200 300 400 500 600
Line input voltage U
N
in V
W
ZWCZM
in Ws
Fig. 7-4: Storable energy in the DC bus for CZM01.3
CE Label, Tests
CEf1.fh7
Fig. 7-5: CE label
High-voltage test according to
EN50178
Routine test with DC2100V 1 s
Insulation test according to EN50178 Routine test with DC500 1 s
Separation between the electrical
circuits of the control and high
voltage power
safe separation according to
EN50178
Clearances and creepage distances according to EN50178
Fig. 7-6: Tests
Storable energy
CE label
Tests:
