Rexroth Indramat ECODRIVE03 Series User Manual

tnemhcattAsrellortnoC evirD 30EVIRDOCE 16-5
Calculating the allowed continuous braking resistor and DC bus power
By connecting the DC bus connections of several DKC and BZM drive
controllers the regenerative power and regenerative continuous power
resulting in the common DC bus is evenly distributed to all ECODRIVE03
components with a braking resistor.
The distribution to the components involved is realized takes place with a
high balancing factor.
P P PBD Ger äte BD DKC BD BZM,,, ( )* ,0 8
P BD, Ger äte : continuous braking resistor power that can be consumed in
continuous operation by all devices on the common DC bus,
in kW
P
BD, DKC : continuous braking resistor power that the drive controller
can consume in continuous operation, in kW
P BD, BZM : continuous braking resistor power that the auxiliary braking
resistor module can consume in continuous operation, in kW
Fig. 16-9: Continuous braking resistor power of all devices on the common DC
bus
P PZW Ger äte ZW, * ,0 8
P ZW, Ger äte : available continuous DC bus power on the common DC bus,
in kW
P ZW : continuous DC bus power of the single devices in kW
Fig. 16-10: Continuous DC bus power of all devices on the common DC bus
See page 4-6.
For central supply and group
supply with DC bus connection
For single source supply and
group supply without DC bus
connection
