4-20 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Number of ECODRIVE03 Units and Auxiliary Components on one DC
bus
Note: The total number of units with bleeder set up on one DC bus
should not exceed max. 12 . Up to this number combinations
as shown below are possible.
Max. number ECODRIVE components on one DC bus (including
supplying unit)
DKC**.3-200 DKC**.3-100 DKC**.3-040 BZM01.3-01 CZM01.3-02
Central supply via
DKC**.3-200
3 8 11 4 2
Central supply via
DKC**.3-200 with GLD 12
3 8 11 4 4
Central supply via
DKC**.3-100
0
(not allowed)
3 622
Group supply with
DC bus connection
DKC**.3-040
0
(not allowed)
0
(not allowed)
12 2 1
Fig. 4-20: Max. number of ECODRIVE03 components on one DC bus
Central supply via DKC**.3-200 with GLD 12:
• 3 * DKC**.3-200
• 4 * DKC**.3-100
• 3 * DKC**.3-040
• 1 * BZM01.3-01
• 3 * CZM01.3-02
Sum of ECODRIVE03 components with bleeder: 12
51:stnenopmoc 30EVIRDOCE lla fo muS
Drive controllers with higher rated current can be replaced by drive
controllers with lower rated current.
Example for central supply via DKC**.3-100 (see table above):
(3 x DKC**.3-100) + (6 x DKC**.3-040) can be replaced by
(9 x DKC**.3-40).
Example:
