ECODRIVE03 Drive Controllers ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 4-95
XE1, XE2 Protective conductor connections for motor and mains
Technical description of connector
See page 4-40: "A look at the drive controller and connector
designations".
Type No. of pins Design
screw-in connection 1 screw-in connection for
ring terminals M5
Fig. 4-155: Design
min. tightening torque
[Nm]
max. tightening torque
[Nm]
0.35.2
Fig. 4-156: Tightening torque
Cross section
single wire
[mm ²]
Max. connectable
cross section
in mm ²
Max. cross section
in AWG
gauge no.:
--52--
Fig. 4-157: Connection cross section
XE1, Protective conductor connection for motor
See page 4-64: "Motor connection".
XE2, Protective conductor connection for mains
Note: PE connection > 10 mm ²
Reason: high leakage currents (EN 50178/1998,
section: 5.3.2.1)
Illustration:
Design:
Tightening torque:
Connection cross section:
