Rexroth Indramat ECODRIVE03 Series User Manual

4-94 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
wire length:
max. 10 m
wire cross section:
min. 10 mm ²,
but not smaller than mains
wire cross section
wire routing
twisted
voltage resistance of single litz to ground:
> 750 V
(e.g.: litz wires - H07)
Note: Connection bridged at delivery.
See page 8-1: "Choke GLD 12".
Wire
DR+, DR-:
Choke type:
