1-2 srellortnoC evirD 30EVIRDOCEmetsyS eht ot noitcudortnI
1.2 An Overview of Individual Components of the
ECODRIVE03 Family
Fa5035f1.fh7
Q1
K1
DKC
NFE
NTM
BZM CZM
FWA
components shown in gray are absolutely necessary.
mains voltage
DC 24 V
fuse
line contactor
drive controller
auxiliary
bleeder module
auxiliary capacitance
module
IKS - ready-made feedback cable
AC motor
IKG - ready-made power cable
line lter for
power supply unit
rmware
power supply unit
NFD
line lter for
power connections
DST
transformer
Fig. 1-2: Overview of individual components
