14 Identifying the Components
14.1 Component designations
Every drive component is labelled with a type designation.
There is a type plate on every unit including the motor.
There is a label around the standard cable (cable brand). Type
designation and length is on this label. (The designation of the actual
cable without connector is printed on the cable sheath.)
The accessories in the bags are either identied with their ID on the bag
or there is a packaging slip.
FA5096f1.fh7
Barcode
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
H1
S1
S3
S2
Barcode
Typenschild
123 4 5 6 7 8 9 1 2 3 4
10 11121314 15161718
567 8
123 4
567 8
2
3
1
4
2
3
1: Basic unit – type plate
2: Unit design – type plate
3: Firmware – type plate
4: Programming module – type plate
Fig. 14-1: Type plates
