Factor F for Computing the Connected Load
Factor F
DC bus continuous power P
ZWD
in kW
0
1
2
3
0,6
Kl0005f1.fh7
0,40,2
Fig. 11-8: Connected load factor for DKC**.3-016-7 (for 3*AC (200 ... 480) V)
Factor F via P
ZWD
for DKC**.3-040-7 and DKC**.3-100-7 (with and without CZM)
0
0,5
1
1,5
2
2,5
3
3,5
0,5 1 2 2,557,5 10 12,5 15
DC bus continuous power P
ZWD
in kW
Factor F
Factor F for
3*AC(200...480)V
Fig. 11-9: Connected load factor for DKC**.3-040-7 and DKC**.3-100-7
