Detail view X1, X3, X10, XS2 and XS3 with cable shield
connection
Fig. 16-20: Detail view X1, X3, X10, XS2 and XS3
• Fasten the cable shields with 2 cable ties each at XS2 or XS3.
Control connection DKC**.3-040/100/200
l
Note: Representing all DKC**.3 – drive controller devices the
following construction examples are based on the device
DKC**.3-040-7.
