4-108 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
DKC 03.3-***-7-FW – Probus-DP Interface
View of command communication interface
FA5028F1.FH7
H33 H30 H31 H32
X30
6
1
5
9
Probus interface
(female, 9 pins)
Diagnostic indicators
Fig. 4-181: View of command communication interface
Technical description of connector
Type No. of pins Design
tinu eht no gnihsuB9BUS-D
Fig. 4-182: Design
Cross sections
single wire
[mm ²]
Cross sections
multi core wire
[mm ²]
Cross sections
in AWG
gauge no.:
-- 0.08-0.5 --
Fig. 4-183: Connection cross sections
Design:
Connection cross sections:
