Rexroth Indramat ECODRIVE03 Series User Manual

4-104 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
DKC 02.3-***-7-FW – SERCOS interface
View of command communication interface
FA5031F1.FH7
H20
ERROR
3
2
1
S20
X20 TX
X21 RX
switch to set transmitting
power
distortion LED of
SERCOS interface
ber optic
connection for SERCOS ring
switch to set data rate
Fig. 4-175: View of command communication interface
Connection diagram for SERCOS interface
DKC02.3
AP5049F1.FH7
optical transmitter
X20
ber optic
cable
optical receiver
X21
SERCOS interface
ber optic
cable
Fig. 4-176: I/O connection allocations for DKC02.3
Connection
SERCOS interface:
