16-2 srellortnoC evirD 30EVIRDOCEtnemhcattA
Calculations with regard to the power and energy allowed on the device
side
]P*mP*lP*kP*n[*f P BZM,ZWD200DKC,ZWD100DKC,ZWD40DKC,ZWD Ger äteZWD, +++=
]P*mP*lP*kP*n[*f P BZM,ZWS200DKC,ZWS100DKC,ZWS40DKC,ZWS Ger äteZWS, +++=
]P*mP*lP*kP*n[*f P BZM,RD200DKC,RD100DKC,RD40DKC,RD Ger äteRD, +++=
]P*mP*lP*kP*n[*f P BZM,RS200DKC,RS100DKC,RS40DKC,RS Ger äteRS, +++=
]W*mW*lW*kW*n[*f W BZM,MAX,R200DKC,MAX,R100DKC,MAX,R40DKC,MAX,R Ger äteR, +++=
PZWD,Ger äte: allowed DC bus continuous power of the units
P
ZWD,DKC*** : allowed DC bus continuous power DKC (40A, 100A, 200A)
P
ZWD,BZM : allowed DC bus continuous power BZM
P
ZWS,Ger äte: allowed DC bus peak power of the units
P
ZWS,DKC*** : allowed DC bus peak power DKC (40A, 100A, 200A)
P
ZWS,BZM : allowed DC bus peak power BZM
P
RD,Ger äte: allowed continuous regenerative power of the units
P
RD,DKC*** : allowed continuous regenerative power
DKC (40A, 100A, 200A)
P
RD,BZM : allowed continuous regenerative power BZM
P
RS,Ger äte: allowed peak regenerative power of the units
P
RS,DKC*** : allowed peak regenerative power DKC (40A, 100A, 200A)
P
RS,BZM : allowed peak regenerative power BZM
W
R,Ger äte: allowed regenerative power of the units
W
R,MAX, DKC*** : max. regenerative power in DKC (40A, 100A, 200A)
W
R,MAX, BZM : max. regenerative power in BZM
f = 1: for operation without DC bus connection
f = 0,8: for operation with DC bus connection
n: number of DKC-040 on the common DC bus
k: number of DKC-100s on the common DC bus
l: number of DKC-200s on the common DC bus
m: number of BZMs on the common DC bus
Fig. 16-6: Power and energy allowed on the device side
Individual data see page 6-1: "Dimensions Auxiliary Bleeder Module
BZM01.3" and following.
