Rexroth Indramat ECODRIVE03 Series User Manual

snoitcennoC sniaMsrellortnoC evirD 30EVIRDOCE 11-1
11 Mains Connections
11.1 General
Note: An ECODRIVE03 drive controller must be permanently
connected to the power supply network.
DKC**.3-040/100/200-7-FW: see page 4-62 X5, DC bus, Motor and
Mains Connections.
DKC**.3-016-7-FW: see page 5-32 X5, Motor and Mains Connections.
Note: Mains lters are available to comply with EMC-limits. For a
selection of information see project planning manual
"Electromagnetic Compatibility (EMC) in Drive and Control
Systems", doc.-type DOK-GENERL-EMV********-PRxx.
11.2 The Ground Conditions of the Power Supply Network
Drive controllers of the ECODRIVE03 family can be operated on three-
phase current networks with grounded star point or external conductors
without potential isolation.
Ungrounded networks (IT networks) present the increased danger of
unallowable phase to ground overvoltages occurring. Drive controllers of
the ECODRIVE03 family can be protected against overvoltages
• By connecting them via an isolating transformer (the star point of the
output side and the PE connection of the power supply unit are linked
on a shared ground rail)
- or -
• If the facility is protected via an overvoltage suppressor.
Connecting ECODRIVE03 drive controllers via an isolating tr
ansformer
oers the best protection against overvoltage as well as the greatest
operating safety.
The periodic overvoltage of ECODRIVE03 drive controllers between
phase (L1, L2, L3) and ground may not exceed 1000 V (threshold value).
Transient overvoltage (< 50 µs) may, as per EN61800-3/1996, equal a
max value of 1000 V phase to phase and 2000 V phase to ground.
Note: If higher overvoltages occur, then they must be limited with the
use of overvoltage suppressors in the cabinet or building.
Note: Mains voltages exceeding the specied range require the use
of a step-down transformer.
Connection
Line lter
Grounded three-phase current
networks
Ungrounded three-phase
networks
Overvoltage
