Rexroth Indramat ECODRIVE03 Series User Manual

11-4 srellortnoC evirD 30EVIRDOCEsnoitcennoC sniaM
Ap5120F1.FH7
K1
1)
K1
Bb
3)
Power o
Power on
Control error
message
Power protection
ext. control voltage +DC 24 V
Safety limit switch
Emergency stop
2)
X1/*
X1/**
X3/*
E- Stop
1): Integrating Bb contacts of more drive controllers and BZM**.* inseries
connection.
(Bb contact: DKC**.3-040/100/200-7-FW: X1/* = X1/7; X1/** = X1/8;
DKC**.3-016-7-FW: X1/* = X1/4; X1/** = X1/6)
2): E-stop for more drive controllers on same contactor.
(Bb contact: DKC**.3-040/100/200-7-FW: X3/* = X3/6;
DKC**.3-016-7-FW: X3/* = X3/7)
3): Switching power of Bb contact must be noted.
Fig. 11-2: Example of generating the E-stop signal
