Rexroth Indramat ECODRIVE03 Series User Manual

4-22 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Arranging the Single source supply
Note: DC bus connection of drive controllers that are connected to
the mains via separate contactors is not allowed!
Ap5109f1.fh7
Kn
DKC**.3
K1
3
3
3
3
BZM1.3
CZM1.3
-040
-100
DKC**.3
-200
3
3
-016
Fig. 4-22: Single source supply
Note: In addition to the illustrated connections of the BZM01.3 at the
DC bus, the following connections must be wired as well:
• Bb contact
• control voltage supply
